Kafka Streams - Scaling up or down

Alexis Seigneurin Oct 06, 2016 0 Comments

Kafka Streams is a new component of the Kafka platform. It is a lightweight library designed to process data from and to Kafka. In this post, I’m not going to go through a full tutorial of Kafka Streams but, instead, see how it behaves as regards to scaling. By scaling, I mean the process of adding or removing nodes to increase or decrease the processing power.

The theory

Kafka Streams can work as a distributed processing engine and scale horizontally. However, as opposed to Spark or Flink, Kafka Streams does not require setting up a cluster to run the application. Instead, you just start as many instances of the application as you need, and Kafka Streams will rely on Kafka to distribute the load.

To do so, Kafka Streams will register all the instances of your application in the same consumer group, and each instance will take care of some of the partitions of the Kafka topic. As a consequence, the maximum number of instances of your application you can start is equal to the number of partitions in the topic.

Scaling is then made very easy:

to scale up: start a new instance of the application and it will take over the responsibility of some partitions from other instances
to scale down: stop an instance and other instances will take care of the no-longer processed partitions.

The application

Given the condition described above, I have created a topic named AUTH_JSON with 4 partitions:

$ .../confluent-3.0.0/bin/kafka-topics --create --topic AUTH_JSON --partitions 4 --replication-factor 1 --zookeeper localhost:2182

I have also created the output topic (AUTH_AVRO) but the number of partitions has no incidence here.

The consumer application is a standalone Java application. I included the dependencies to the Kafka client and to Kafka Streams using Maven:

<dependency>
    <groupId>org.apache.kafka</groupId>
    <artifactId>kafka-clients</artifactId>
    <version>0.10.0.0</version>
</dependency>
<dependency>
    <groupId>org.apache.kafka</groupId>
    <artifactId>kafka-streams</artifactId>
    <version>0.10.0.0</version>
</dependency>

The code is pretty simple:

it reads JSON strings from the AUTH_JSON Kafka topic (builder.stream)
it parses the JSON strings into business objects (flatMapValues), applies some processing to the objects (first call to mapValues) and converts the objects to Avro (second call to mapValues)
it writes the result to the AUTH_AVRO Kafka topic (to)

public static void main(String[] args) throws SchedulerException {
    Properties props = new Properties();
    props.put(StreamsConfig.APPLICATION_ID_CONFIG, "auth-converter");
    props.put(StreamsConfig.BOOTSTRAP_SERVERS_CONFIG, "localhost:9092");
    props.put(StreamsConfig.ZOOKEEPER_CONNECT_CONFIG, "localhost:2181");
    props.put(StreamsConfig.KEY_SERDE_CLASS_CONFIG, Serdes.String().getClass().getName());
    props.put(StreamsConfig.VALUE_SERDE_CLASS_CONFIG, Serdes.String().getClass().getName());
    props.put(ConsumerConfig.AUTO_OFFSET_RESET_CONFIG, "latest");

    KStreamBuilder builder = new KStreamBuilder();
    KStream<String, String> kafkaInput = builder.stream("AUTH_JSON");
    kafkaInput.flatMapValues(value -> JsonToAuth.call(value))
            .mapValues(value -> DataProcessMap.call(value))
            .mapValues(a -> AvroSerializer.serialize(a))
            .to(Serdes.String(), Serdes.ByteArray(), "AUTH_AVRO");

    KafkaStreams streams = new KafkaStreams(builder, props);
    streams.start();
}

As an addition, I have a Quartz job that prints every second the number of records that have been processed in the past second.

Running separately, a producer sends 2000 records every second (more precisely 20 records every 10 milliseconds) to the AUTH_JSON Kafka topic. Since the topic has 4 partitions, that’s 500 records per partition every second (5 records per partition every 10 milliseconds).

Normal run

When we start a first instance of the consumer:

the application joins the consumer groupauth-converter
it then takes responsibility for processing the 4 partitions of the topic (AUTH_JSON-2, AUTH_JSON-1, AUTH_JSON-3 and AUTH_JSON-0).

11:00:22,152 org.apache.kafka.common.utils.AppInfoParser - Kafka version : 0.10.0.0
11:00:22,152 org.apache.kafka.common.utils.AppInfoParser - Kafka commitId : b8642491e78c5a13
11:00:22,156 org.apache.kafka.streams.KafkaStreams - Started Kafka Stream process
...
11:00:22,331 org.apache.kafka.clients.consumer.internals.AbstractCoordinator - Successfully joined group auth-converter with generation 1
11:00:22,332 org.apache.kafka.clients.consumer.internals.ConsumerCoordinator - Setting newly assigned partitions [AUTH_JSON-2, AUTH_JSON-1, AUTH_JSON-3, AUTH_JSON-0] for group auth-converter
...
11:00:22,702 com.seigneurin.Main - Records processed: 0
11:00:23,705 com.seigneurin.Main - Records processed: 0

Now, if we start the producer, the consumer starts consuming 2000 records per second:

11:00:52,703 com.seigneurin.Main - Records processed: 2292
11:00:53,704 com.seigneurin.Main - Records processed: 2608
11:00:54,706 com.seigneurin.Main - Records processed: 2000
11:00:55,704 com.seigneurin.Main - Records processed: 2000

Scaling up

Now, let’s start a second instance of the application (just run the same jar one more time in parallel):

the new instance joins the same consumer groupauth-converter
it takes responsibility for processing 2 partitions of the topic (AUTH_JSON-2 and AUTH_JSON-3)
it immediately starts processing 1000 records per second.

11:01:29,546 org.apache.kafka.common.utils.AppInfoParser - Kafka version : 0.10.0.0
11:01:29,546 org.apache.kafka.common.utils.AppInfoParser - Kafka commitId : b8642491e78c5a13
11:01:29,551 org.apache.kafka.streams.KafkaStreams - Started Kafka Stream process
...
11:01:31,402 org.apache.kafka.clients.consumer.internals.AbstractCoordinator - Successfully joined group auth-converter with generation 2
11:01:31,404 org.apache.kafka.clients.consumer.internals.ConsumerCoordinator - Setting newly assigned partitions [AUTH_JSON-2, AUTH_JSON-3] for group auth-converter
...
11:01:32,085 com.seigneurin.Main - Records processed: 435
11:01:33,086 com.seigneurin.Main - Records processed: 1263
11:01:34,086 com.seigneurin.Main - Records processed: 1000

If we look at the first instance, we can see:

it was processing 2000 records per second
it stops processing the 4 partitions and switches to processing only 2 of them (AUTH_JSON-1 and AUTH_JSON-0)
it then only processes 1000 records per second.

11:01:29,704 com.seigneurin.Main - Records processed: 2000
11:01:30,707 com.seigneurin.Main - Records processed: 2000
11:01:31,390 org.apache.kafka.clients.consumer.internals.ConsumerCoordinator - Revoking previously assigned partitions [AUTH_JSON-2, AUTH_JSON-1, AUTH_JSON-3, AUTH_JSON-0] for group auth-converter
...
11:01:31,401 org.apache.kafka.clients.consumer.internals.ConsumerCoordinator - Setting newly assigned partitions [AUTH_JSON-1, AUTH_JSON-0] for group auth-converter
...
11:01:31,705 com.seigneurin.Main - Records processed: 1682
11:01:32,705 com.seigneurin.Main - Records processed: 1000
11:01:33,702 com.seigneurin.Main - Records processed: 1000

Scaling down

Now, let’s kill one of the instances:

11:01:43,087 com.seigneurin.Main - Records processed: 1000

Process finished with exit code 130

Here is what happens on the remaining instance:

before stopping the other instance, it is processing 1000 records per second
for 30 seconds, nothing changes: it keeps processing 1000 records per second
once the 30 seconds period is over, this instance takes back the responsibility of the 4 partitions (AUTH_JSON-2, AUTH_JSON-1, AUTH_JSON-3 and AUTH_JSON-0)
once done, it catches up with the processing of the records that have not been processed by the now-dead instance
it finally runs smoothly again, processing 2000 records per second.

11:01:42,705 com.seigneurin.Main - Records processed: 1000
11:01:43,702 com.seigneurin.Main - Records processed: 1000
11:01:44,704 com.seigneurin.Main - Records processed: 1000
...
11:02:12,705 com.seigneurin.Main - Records processed: 1000
11:02:13,410 org.apache.kafka.clients.consumer.internals.ConsumerCoordinator - Revoking previously assigned partitions [AUTH_JSON-1, AUTH_JSON-0] for group auth-converter
...
11:02:13,415 org.apache.kafka.clients.consumer.internals.ConsumerCoordinator - Setting newly assigned partitions [AUTH_JSON-2, AUTH_JSON-1, AUTH_JSON-3, AUTH_JSON-0] for group auth-converter
...
11:02:13,705 com.seigneurin.Main - Records processed: 6589
11:02:14,705 com.seigneurin.Main - Records processed: 29937
11:02:15,704 com.seigneurin.Main - Records processed: 10792
11:02:16,703 com.seigneurin.Main - Records processed: 2000
11:02:17,705 com.seigneurin.Main - Records processed: 2000

The interesting behavior here is obviously that the handover was not immediate but, instead, a 30 seconds timeout was applied for detecting that an instance was dead. This is actually necessary so that, if an instance temporarily lags behind (brief network connectivity issue, garbage collection…), other instances will not aggressively take over their work.

The timeout can be configured through the ConsumerConfig.SESSION_TIMEOUT_MS_CONFIG ("session.timeout.ms") setting which is documented as follows;

The timeout used to detect failures when using Kafka’s group management facilities. When a consumer’s heartbeat is not received within the session timeout, the broker will mark the consumer as failed and rebalance the group. Since heartbeats are sent only when poll() is invoked, a higher session timeout allows more time for message processing in the consumer’s poll loop at the cost of a longer time to detect hard failures. See also MAX_POLL_RECORDS_CONFIG for another option to control the processing time in the poll loop. Note that the value must be in the allowable range as configured in the broker configuration by group.min.session.timeout.ms and group.max.session.timeout.ms.

And the value of this setting was actually printed then the application started:

11:00:21,985 org.apache.kafka.clients.consumer.ConsumerConfig - ConsumerConfig values:
    ...
    session.timeout.ms = 30000
    ...

Wrapping up

It is striking how easy it is to scale a Kafka Streams application up or down. I particularly like the fact that this operation is dynamic, as opposed to Spark Streaming that statically allocates resources when the job starts.

Keep in mind to create the Kafka topic with enough partitions so that you can scale your application.
